ECX08A

Functions and Benefits
  • Post & pre compensated L.S.
  • Pre-arranged for close & open circuit.
  • Compact directional valve with low pressure losses.
  • Interchangeable spools.
  • Wide range of auxiliary valves on working ports.
  • Availability of manual, pneumatic, hydraulic, EHP proportional (can-bus) actuations.
Number of sections
1 - 12
Nominal inlet flow
120 i/min [32 GPM]
Spool pitch
36mm [1.4 in]
Work port flow
100 l/min [26 GPM]
Stand-by pressure
14 bar [200 psi]
Inlet working pressure
350 bar [5100 psi]
Section working pressure
380 bar [5500 psi]

EBI motion controls provides a broad choice of directional control valves expertly developed and tested to meet different market sectors’ needs.

ECX08A are suited for specialized applications
for a variety of mobile equipment such as:
